File:Amstrad PC4386SX power supply 3-pin drive lead.jpg
Size of this preview: 497 × 368 pixels.
Original file (497 × 368 pixels, file size: 34 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A three-way lead from an Amstrad PC4386SX power supply, labelled by the photographer: ground (black wire), 12 V (brown) and 5 V (red). The photographer did not say which drive it feeds; the file name's "drive lead" is a description of its likely use, not his.
Source
[edit | edit source]
Vogons forum thread "AMSTRAD PC 5086 - Floppy Drive Problems", reply 11 by gca, 2 August 2021 (retrieved 2026-10-02).
Author
[edit | edit source]
gca (Vogons forum user).
Licence
[edit | edit source]
Public domain, as marked on the forum attachment.
