File:Amstrad PC4386SX power supply main connector.jpg
Size of this preview: 600 × 505 pixels.
Original file (600 × 505 pixels, file size: 64 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
The main output connector of an Amstrad PC4386SX power supply, labelled by the photographer: 12 V on the yellow wire, ground on the black wires and 5 V on the pink wires.
Source
[edit | edit source]
Vogons forum thread "AMSTRAD PC 5086 - Floppy Drive Problems", reply 11 by gca, 2 August 2021 (retrieved 2026-10-02).
Author
[edit | edit source]
gca (Vogons forum user).
Licence
[edit | edit source]
Public domain, as marked on the forum attachment.
