File:Apple IIc logic board 820-0115-C.jpg
Size of this preview: 584 × 600 pixels. Other resolution: 1,920 × 1,971 pixels.
Original file (1,920 × 1,971 pixels, file size: 1.2 MB, MIME type: image/jpeg)
Summary
[edit | edit source]
Top view of an original Apple IIc main logic board, marked MAIN LOGIC 820-0115-C, Apple Computer 1983, removed from the case. The 65C02, IOU, MMU, two 6551 ACIAs, the KR3600-PRO keyboard encoder and the RAM column on the right edge are visible.
Source
[edit | edit source]
Wikimedia Commons, File:Apple-IIc-Motherboard-Flat-Top.jpg (retrieved 2026-09-30), 1920 px Commons thumbnail.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain. Attribution: Evan-Amos, via Wikimedia Commons.
