Power supply circuit of the Atari 822 thermal printer board, from Atari technical specification TS015897-01: the 9 V AC input J205 and C208, the power switch S200, the bridge CR206 to CR209 with C205 and C206 feeding the 78M05 regulator A202 for +5 V, the voltage doubler C207 and CR204 with CR203 and C203 for +15 V, and the TIP122 Q202 with the 13 V zener CR202 and C204 for +12 V.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Rendered at 200 dpi from File:Atari 822 Thermal Printer Technical Specifications TS015897-01.pdf, page 2, cropped and converted to greyscale, 2026-10-06.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Atari, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Atari, Inc. Reproduced from the technical specification for repair reference.
