File:Atari Jaguar CD with top case removed.jpg
Size of this preview: 800 × 494 pixels. Other resolution: 1,920 × 1,185 pixels.
Original file (1,920 × 1,185 pixels, file size: 309 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
An Atari Jaguar CD unit with the top case removed, showing the Philips CD transport in its mounting on the shielded main board and the cartridge pass-through connector behind it. Photographed by Evan-Amos on 19 June 2014.
Source
[edit | edit source]
Wikimedia Commons, File:Atari-Jaguar-CD-Bare-Teardown2.jpg (retrieved 2026-10-04). Downscaled copy.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released by the author on Wikimedia Commons).
