File:Atari Lynx II motherboard underside.jpg
Size of this preview: 800 × 415 pixels. Other resolution: 1,920 × 997 pixels.
Original file (1,920 × 997 pixels, file size: 480 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Underside of an Atari Lynx II main board (C104471-001 Rev. A), showing the copper RF shield sheet soldered to the board around the cartridge connector (marked C101985-001). Photographed by Evan-Amos on 10 April 2014.
Source
[edit | edit source]
Wikimedia Commons, File:Atari-Lynx-II-Motherboard-Back.jpg (retrieved 2026-10-04). Downscaled copy.
