Summary
edit
Two laptop battery packs (10.8 V 3800 mAh and 14.8 V 4400 mAh) with a single Panasonic CGR18650 cell and a ruler. The pack voltages reveal the series count: 10.8 V is 3S, 14.8 V is 4S. Used on the Battery Refurbishment guide.
Licensing
edit
Author: Biopilz
Licence: CC BY-SA 3.0
Source: Wikimedia Commons, File:Comparison of three Lithium-ion batteries.jpg
