Summary

Electrolytic capacitors removed from the H7878 power supply of a DECstation 5000/240 during Rob Jarratt's 2017 repair, laid out on the machine: a Nippon Chemi-Con KMG 820 µF 200 V input smoothing capacitor, SXE 8200 µF and 3300 µF 10 V output capacitors and smaller output-stage parts. See DECstation 5000 Capacitor Replacement Guide.

Source

https://robs-old-computers.com/2017/10/01/decstation-5000-model-240-psu-fixed/ (retrieved 2026-10-01)

Author

Rob Jarratt, Rob's Old Computers.

Licence

No licence is stated on the source page. Credited to the author and used for repair reference.
