Recap-a-Mac's annotated photograph of the backlit Macintosh Portable logic board (820-0256-03), marking the electrolytic capacitors to replace by value and voltage: four 1 µF 50 V, one 4.7 µF 25 V, two 10 µF 16 V, four 47 µF 16 V, four 100 µF 25 V radial, one 220 µF 25 V radial and two 470 µF 25 V axial.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Recap-a-Mac, "Macintosh Portable (backlight)", https://recapamac.com.au/macintosh-portable-backlight/ (image https://recapamac.com.au/wp-content/uploads/2020/03/portable_backlight_recap.jpg, retrieved 2026-10-02).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Recap-a-Mac (recapamac.com.au).
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Copyright Recap-a-Mac. No licence stated at the source. Used with credit for repair reference.
