DEC's drawing of the PDP-11X44 system: the PDP-11/44 BA11-A mounting box at the top of its 40-inch system cabinet, with the dual TU58 tape drive below the front bezel.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
DEC, PDP-11/44 System User's Guide, EK-11044-UG-003, July 1981, frontispiece, rendered from the scan at bitsavers.org (retrieved 2026-10-02).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Digital Equipment Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Digital Equipment Corporation. Reproduced from DEC service documentation for preservation and repair reference, with the source cited.
