Annotated photograph of an Apple logic board marked 820-0816-D (c) 1997 with a 250 MHz processor, with its surface-mount electrolytic capacitors circled and listed: twelve 47 µF 16 V (pink), six 100 µF 6.3 V (blue) and one 100 µF 25 V (yellow, C137). MacDat uses this image for the Power Macintosh 5500, the Power Macintosh 6500 and the Twentieth Anniversary Macintosh. Downscaled from 3876 px to 2200 px wide.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
MacDat, Capacitor Reference Library, Twentieth Anniversary Macintosh, image file 5500_6500_tam_logicboard.png (retrieved 2026-10-02).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Photograph and information sent to MacDat by Daan; annotation as published by MacDat.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
No licence stated at the source. Copyright the photographer and MacDat. Hosted for repair reference with the source credited.
