File:AppleCD 150 CDU-541-25 capacitors C427-C430.jpg
Size of this preview: 550 × 400 pixels.
Original file (550 × 400 pixels, file size: 68 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Detail of the Sony CDU-541-25 main board from an AppleCD 150: the four surface-mount electrolytic capacitors C427, C428, C429 and C430, each marked 100 (µF) 6.3 V, beside IC407.
Source
[edit | edit source]
Cropped from bitsavers.org, pdf/sony/cdrom/CDU541-25_AppleCD_150/pcb.jpg (retrieved 2026-10-04); see File:AppleCD 150 Sony CDU-541-25 main board.jpg.
Author
[edit | edit source]
Not recorded at the source (bitsavers.org archive).
Licence
[edit | edit source]
No licence stated at the source. Used for repair reference, with the source credited.
