File:AppleCD 150 Sony CDU-541-25 main board.jpg
Size of this preview: 436 × 599 pixels. Other resolution: 1,600 × 2,197 pixels.
Original file (1,600 × 2,197 pixels, file size: 944 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
The main circuit board (Sony 1-631-957-15) of the Sony CDU-541-25 CD-ROM drive unit from an AppleCD 150, component side. The surface-mount aluminium electrolytic capacitors C427-C430 (100 µF 6.3 V) sit beside the firmware EPROM; the 47 µF and 10 µF parts are near the 78M05 regulator at lower left. Downscaled from the original scan.
Source
[edit | edit source]
bitsavers.org, pdf/sony/cdrom/CDU541-25_AppleCD_150/pcb.jpg (retrieved 2026-10-04).
Author
[edit | edit source]
Not recorded at the source (bitsavers.org archive).
Licence
[edit | edit source]
No licence stated at the source. Used for repair reference, with the source credited.
