Summary

Part of an Apple Lisa I/O board, showing the four-cell battery pack with corrosion at the cell ends, the battery switch (marked ON) below it, the COP421 microcontroller (341-0064-A) and the surrounding components. Photographed during a teardown.

Source

https://commons.wikimedia.org/wiki/File:Apple_Lisa_Teardown_(15471694183).jpg (retrieved 2026-09-30), downscaled to 1600 px. Originally from Flickr.

Author

Dave Jones from Australia

Licence

CC BY 2.0, https://creativecommons.org/licenses/by/2.0/
