Close view inside an Apple LocalTalk connector: the switch on the back of a 3-pin mini-DIN socket that connects the 100-ohm terminating resistor when no cable is plugged in, with R1 to R5, C1 and the Tokin 157-0049-C transformer.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Wikimedia Commons, File:Apple LocalTalk box interior 2 - auto termination switch.jpg (retrieved 2026-10-04). Downscaled to 1920 px wide.
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Dale Mahalko (DMahalko)
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
CC BY-SA 3.0. Photograph by Dale Mahalko, via Wikimedia Commons.
