An NTSC Atari 7800 with the top case removed, showing the RF shield over the board, the four console buttons along the front edge and the main filter capacitor at the right rear.
Source
[edit | edit source]
Wikimedia Commons, File:Atari-7800-Console-Breakdown-01.jpg (retrieved 2026-10-01). Downscaled for this wiki.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author on Wikimedia Commons).
