File:DEC PDP-11-34 Unibus backplane with modules.jpg
Size of this preview: 800 × 533 pixels. Other resolution: 1,920 × 1,280 pixels.
Original file (1,920 × 1,280 pixels, file size: 529 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Top view into a PDP-11/34 box showing the hex-height modules in the Unibus backplane slots, with flat cables to the controllers. The Commons description lists the CPU boards, bootstrap ROM, a tape controller, a disk controller and an A/D converter.
Source
[edit | edit source]
Wikimedia Commons, File:PDP-11-34 unibus slots.jpg (retrieved 2026-10-02), downscaled to 1920 px wide.
Author
[edit | edit source]
Autopilot (Wikimedia Commons).
Licence
[edit | edit source]
CC BY-SA 3.0. Attribution: Autopilot.
