File:Amstrad PC-MM main PCB layout.png
Size of this preview: 800 × 551 pixels. Other resolution: 1,870 × 1,287 pixels.
Original file (1,870 × 1,287 pixels, file size: 465 KB, MIME type: image/png)
Summary
[edit | edit source]
The main printed circuit board of the PC-MM monochrome monitor, which also holds the PC1512's power supply, component side, as drawn on page 42 of Amstrad's PC1512 / PC-MM / PC-CM service manual (two scan pages joined).
Source
[edit | edit source]
Rendered from PDF pages 47–48 (printed page 42) of the hosted File:Amstrad PC1512 Service Manual.pdf.
Author
[edit | edit source]
Amstrad plc.
Licence
[edit | edit source]
Copyright Amstrad plc. Hosted for preservation and repair reference, with the source cited.
