Top side of an NTSC Atari 7800 motherboard with the RF shields removed. The MARIA (C024674-30), the 6502 marked C014806C-29, two Sony CXK5816 RAMs, the C024922B ROM, the TIA, the 6532 and the C024629 RF modulator can be read on it.
