File:Atari SC1224 Goldstar CA-3 chassis adjustment points.png
Summary
[edit | edit source]
"Chassis important parts", the labelled photograph of the CA-3 chassis of the Goldstar-built Atari SC1224 from Atari's SC1224 service manual (printed page 21). It marks the user and service controls with their designators: H.WIDTH coil L702, SUB BRIGHT R742, the flyback (FBT) with its SCREEN and FOCUS controls, HOLD DOWN R725, H-HOLD R716, H-POSITION R710, V-HOLD R603, V-SIZE R616, V-LIN R635, V-CENTER R626, SIDE PCC R621, the R, G and B DRIVE, CUT OFF and LEVEL presets, and the front controls. Extracted at the scan's native 150 dpi and cropped.
Source
[edit | edit source]
Cropped from File:Atari SC1224 Service Manual (CA-3 chassis).pdf, PDF page 17.
Author
[edit | edit source]
Atari Corporation
Licence
[edit | edit source]
Copyright Atari Corporation. Hosted for preservation and repair reference, with the source cited.
