Amstrad PenPad PDA600 Troubleshooting Guide
.jpg)
Most faults on the Amstrad PenPad PDA600 come from its power supply, its pen digitiser and handwriting recognition, or its memory cards. Amstrad's French manual has a troubleshooting table and a list of on-screen messages; for anything beyond them it refers the owner to the dealer.[1] Routine care, including the lithium cell and pen calibration, is in the Amstrad PenPad PDA600 Maintenance Guide.
Power and memory
[edit | edit source]| Symptom | Probable cause | Action |
|---|---|---|
| No response to the stylus | Software hang | Switch off, wait a few seconds and switch on again. |
| Screen blank or unreadable at switch-on | Contrast setting; cells fitted wrongly | Adjust the contrast icon at the top left. Check the AA cells are the right way round. If the screen is still blank, Amstrad's manual refers you to the dealer. |
| Battery menu opens by itself | Gauge at REMPLACER! | Switch off and change the AA cells as soon as possible. |
| Lithium cell warning | CR2032 backup cell low | With good AA cells fitted, switch off and replace the CR2032. |
| Memory lost after changing cells | Cells removed with the power on, or AA and lithium cells removed together, or a flat backup cell | Amstrad warns that either of the first two can lose all data. Data cannot be copied back from a card, but a card of 256 KB or more can be used in place of the internal memory; otherwise re-enter from a printout. |
After switching off, wait a few seconds before switching on again.[1] The PenPad turns itself off after five minutes without use, which is not a fault.[1][2] Corroded battery contacts from leaking cells are covered in Battery Explosion, Capacitor or Corrosion Damage.
Display
[edit | edit source]- Faint or dark screen: touch the dark or light half of the contrast icon at the top left and hold it, pressing lightly, until the contrast is right.[1]
- Hard to read in dim light: Byte found the contrast poor in dim lighting, made worse by the thick and highly reflective digitiser film over the LCD. This is how the PenPad was built.[2]
- A single dot left on a diary page shows as a drawing in the weekly view. Rub it out with the eraser icon, or delete the whole page by touching a binder ring and dragging the page off the screen.[1]
Pen and handwriting recognition
[edit | edit source]| Symptom | Probable cause | Action |
|---|---|---|
| Line drawn does not appear under the stylus tip | Pen calibration has drifted | Recalibrate the pen from the configuration menu: hold the PenPad normally and press each target gently until it beeps. |
| A letter, such as T, is still misread after training | The stroke starts outside its box, or calibration is off | Recalibrate the pen, then try again. |
| Recognition poor overall | Character library trained badly or by another user | Rewrite the whole character library from the configuration menu. Stored text is not affected. |
| Address book out of alphabetical order; search finds unrelated words | The PenPad stores 0 and O, and 1 and I, as the same character, so a name may have been stored as starting with a digit | Retrain those characters so they differ: a slashed zero, and an I with serifs or a dot. |
| Message saying a name begins with a digit | First letter recognised as a number | Rewrite the first character. |
| Beep when entering a regular event | No box ticked to say when it repeats | Tick the repeat box. |
Recognition works only on single characters written in boxes, not on joined writing, and improves as misread characters are retrained.[2] The trained library cannot be saved outside the PenPad, so a reset or memory loss means training it again.[2]
Memory cards and messages
[edit | edit source]| Message | Meaning | Action |
|---|---|---|
| CARTE? | The card icon was touched with no card in the slot | Touch the screen to clear the message. |
| CHANGEE | A card was inserted without switching off | Switch off, wait a few seconds and switch on. |
| ECHEC | The PenPad could not read the card | Touching the screen while the message shows overwrites the card and destroys its data. A defective card cannot be used. |
| PROTEGEE | The PCMCIA card is write-protected | Remove the card's write protection, following the card maker's instructions. |
| MEMOIRE SATUREE | Memory full | Delete entries you no longer need, starting with handwritten notes, which use the most memory; or add a card. |
| Copy warning | Copying the internal memory to a card that already holds data | Continuing erases the card's contents. |
| Clash warning | Two appointments at the same time on the same day | Change one of them. |
Cards from 32 KB to 2 MB work; larger cards do not. A card used in another computer is formatted, and a card from an Amstrad NC100 Notepad brings up a warning before its data is overwritten.[1] A card holds its data with its own battery, shown as BON or REMPLACER! in the desk menu; a card whose battery has failed loses its contents.[1]
Notes section and to-do list
[edit | edit source]- The notes section seems to have disappeared and there are no pages left: insert new pages with the new-page icon.[1]
- The to-do list is full: add a new item with the new-page icon.[1]
Printing and PC link
[edit | edit source]The PenPad prints and transfers through its serial connector at fixed settings of 9600 baud, 8 data bits, no parity and 1 stop bit, which cannot be changed on the PenPad; set the printer to match. A parallel printer needs a serial-to-parallel converter.[1] The connector pinout and the null-modem wiring are on the Amstrad PenPad PDA600 page.
